Y-800 Automatic Transfer Switch Controller - 10A Output, IP20, Reliable China Factory Suppliers
LMS1-LA Series Manual
LMS1-LA as our ingenuity research and development of a new generation of dual power automatic transfer switch, in the performance and technology to achieve a major breakthrough. The product provides 63A, 125A, 250A, 400A, 630A and other rated current specifications, whether it is the continuous operation of massive servers in data centers, or the uninterrupted power supply of life support equipment in hospital ICU wards, the stable operation of elevator and fire fighting system in high-rise buildings can fully meet the power demand in different scenarios.
Its switching speed can be called industry-leading, switching time only 10ms-50ms, with millisecond response speed to complete power conversion. In the data center, the LMS1-LA automatic transfer switch can switch to the standby power supply in a very short period of time in the face of sudden power failure, avoiding data loss and system collapse caused by momentary power failure; in the hospital environment, the LMS1-LA automatic transfer switch can switch to the standby power supply in a very short period of time, millisecond-level power switching can guarantee the stable operation of precision instruments and first-aid equipment in operating rooms, and escort the safety of patients. When applied to high-rise buildings, fast power changeover ensures smooth parking of elevators, normal operation of fire fighting systems and improved building Factor of safety.
The transfer switch is composed of a high performance excitation contactor and an intelligent controller. When working, the electromagnetic coil produces a strong and stable attraction to drive the switching action to ensure the instant completion of power switching. This feature not only effectively guarantees the rapid switching of the power supply when the equipment is powered off, but also realizes the seamless connection of the power supply, which provides a reliable and solid power guarantee for the equipment with strict requirements for power continuity.
The Y-800 busbar controller is used to control three frame circuit breakers, realize the conversion of two power supplies and the busbar connection on the load side. It is based on microprocessor, which can detect the voltage of two three-phase incoming lines accurately, make accurate judgment on the voltage abnormality (overvoltage, undervoltage, over frequency, under frequency, missing phase, reverse phase sequence), complete the power conversion and the connection and disconnection of the bus on the load side according to the given logic, and output the passive control switch to complete the control of the load, display the system status and other functions. The controller is equipped with electrical interlock accessories, which cooperate with mechanical interlock to realize redundant interlock system and improve the reliability of operation. The product has compact structure, simple wiring and high reliability. It can be widely used in electrical automatic control systems of power, telecommunications, petrochemical, mining, rail transit, municipal, data center, intelligent building and other industries.
Model Description
Main Technical Parameters
| Project | Parameter | Description / Value |
|---|---|---|
| Working Voltage | 1. B+ and B- terminals: DC (12–60V) | 2. AC power supply (90–305V) | |
| Power Consumption | < 6W | |
| AC Input Voltage | Alternating Current System | |
| Three-phase four-wire (L-L) | (80 ~ 625) V | |
| Three-phase three-wire (L-L) | (80 ~ 625) V | |
| Single phase two-wire (L-N) | (50 ~ 360) V | |
| Two-phase three-wire (L-L) | (80 ~ 625) V | |
| Voltage Resolution: 1V | Accuracy: 2% | ||
| AC Cycle | Rated: 50/60Hz | Range: 15Hz – 75Hz | Resolution: 0.1Hz | Precision: 0.1Hz | |
| Programmable Output Relay Capacity | 10A 277VAC passive output | |
| 10A 250VAC passive output | ||
| RS485 Interface | Isolated half-duplex mode with configurable baud rates of 2400, 4800, 9600, and 19200. The Modbus-RTU communication protocol supports a maximum transmission distance of 1000 meters. | |
| EMC Test Criteria | Complies with GB/T 14048.11-2024 and IEC/EN 60947-6-1 | |
| Outline Dimension | 260mm × 180mm × 55mm | |
| Pore Size | 167mm × 236mm | |
| Working Temperature | (-20 ~ +70) ℃ | |
| Working Humidity | (20 ~ 93) %RH | |
| Storage Temperature | (-30 ~ +80) ℃ | |
| Level of Protection | IP20 | |
| Weight | Approx. 1 kg | |
Frequently Asked Questions
What is the Y-800 busbar controller used for?
The Y-800 busbar controller is designed to control three frame circuit breakers, enabling the conversion of two power supplies and managing busbar connections on the load side. It is widely applied in power, telecommunications, data centers, and intelligent building systems.
What types of voltage abnormalities can the Y-800 detect?
The Y-800 can accurately detect and respond to overvoltage, undervoltage, over frequency, under frequency, missing phase, and reverse phase sequence conditions across two three-phase incoming lines.
What communication interface does the Y-800 support?
The Y-800 features an isolated RS485 half-duplex interface supporting Modbus-RTU protocol with configurable baud rates (2400, 4800, 9600, 19200 bps) and a maximum transmission distance of 1000 meters.
What is the operating temperature range of the Y-800 controller?
The Y-800 operates reliably within a working temperature range of -20°C to +70°C, and can be stored in temperatures ranging from -30°C to +80°C.
What EMC standards does the Y-800 comply with?
The Y-800 busbar controller complies with GB/T 14048.11-2024 and IEC/EN 60947-6-1 electromagnetic compatibility test standards, ensuring reliable performance in industrial environments.
How does the Y-800 ensure operational safety and reliability?
The Y-800 is equipped with electrical interlock accessories that work in conjunction with mechanical interlocks to form a redundant interlock system. This dual-layer protection significantly improves operational reliability and prevents accidental switching faults.
